Kenwood PW-A series User Manual

PW-A
36
PARTS LIST
Name & Description
F10-2596-04 1 1 SHIELD PLATE
F20-3080-03 1 1 INSULATOR SHEET; TOP
F20-3081-12 1 1 INSULATOR SHEET; CPU UNIT
F20-3086-03 1 1 INSULATOR SHEET; AMP UNIT
F20-3087-03 1 1 INSULATOR SHEET; AMP UNIT
F20-3088-14 2 2 INSULATOR SHEET; HEAT SINK
H10-2906-15 1 1 FOAMED STYREN PAD; FRONT
H10-2907-15 1 1 FOAMED STYREN PAD; REAR
H13-1213-05 1 1 CARTON BOARD
H20-1743-04 1 1 VINYL COVER
H53-0368-03 1 1 CARTON BOX
J02-0363-04 4 4 RUBBER FOOT
J21-4843-04 2 2 BRACKET; HANDLE
J21-9047-04 3 3 BRACKET; FET
J21-9048-02 1 1 BRACKET; POWER TRANSFORMER
J32-1295-05 2 BOSS
J59-0403-05 4 4 NYLON RIVET
K01-0556-15 1 1 HANDLE
K21-0907-14 1 1 KNOB; ENCORDER
K29-7251-11 1 1 BUTTON; CLEAR
K29-7257-02 2 2 KNOB; TERMINAL (RED)
K29-7258-02 1 1 KNOB; TERMINAL (BLACK)
K29-7259-02 1 1 KNOB; TERMINAL (WHITE)
K29-7260-02 2 2 KNOB; TERMINAL (BLUE)
L07-1597-05 1 1 POWER TRANSFORMER
N09-4557-05 4 4 SCREW, SEMS PAN HD (M4✽60)
N09-4558-05 2 2 SPECIAL SCREW (M3✽6)
N10-2030-41 2 HEXAGON NUT
N11-0030-41 1 1 FRANGE NUT (M3)
N11-0040-41 2 2 FRANGE NUT (M4)
N15-1030-41 2 PLAIN WASHER
N16-0030-41 2 SPRING WASHER
N17-1030-41 2 TOOTHED LOCK WASHER
N32-3008-41 1 1 SCSREW, FLAT HD (M3✽8)
N32-4010-41 2 2 SCSREW, FLAT HD (M4✽10)
N33-3006-41 6 6 SCREW, OVAL HD (M3✽6)
N35-3004-41 2 SCREW, BINDING HD (M3✽4)
N66-3008-41 27 27 SCREW, SEMS PAN HD (M3✽8)
N66-4008-41 4 4 SCREW, SEMS PAN HD (M4✽8)
N66-4010-41 8 8 SCREW, SEMS PAN HD (M4✽10)
N66-4035-41 2 2 SCREW, SEMS PAN HD (M4✽35)
N67-3010-41 5 5 SCREW, SEMS PAN HD (M3✽10)
N67-3016-41 5 5 SCREW, SEMS PAN HD (M3✽16)
X66-1820-01 1 1 PANEL UNIT
X68-2210-07 1 POWER SUPPLY UNIT (PW26-1AT)
X68-2210-11 1 POWER SUPPLY UNIT (PW26-1ATS)
X73-2320-08 1 1 AMP UNIT
X77-2380-01 1 1 CPU UNIT
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
3
-00
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
-02
Parts No.
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
Name & Description
A29-0527-24 PANEL; IF GP
B42-3819-05 SERIAL NO. PLATE
B42-3821-05 LABEL (7✽3)
B63-0567-10 INSTRUCTION MANUAL
F20-3090-14 INSULATOR SHEET
H25-0858-04 VINYL COVER
H53-0335-04 CARTON BOX
J59-0403-05 NYLON RIVET
X72-1540-00 INTERFACE UNIT
A29-0528-04 PANEL; IF RS
B42-3819-05 SERIAL NO. PLATE
B42-3821-05 LABEL (7✽3)
B63-0567-10 INSTRUCTION MANUAL
F20-3090-14 INSULATOR SHEET
H25-0858-04 VINYL COVER
H53-0335-04 CARTON BOX
J59-0403-05 NYLON RIVET
N09-4535-05 SPECIAL SCREW
X72-1540-01 INTERFACE UNIT
A29-0533-04 PANEL; IF USB
B42-3819-05 SERIAL NO. PLATE
B42-3821-05 LABEL; 7✽3
B63-0567-10 INSTRUCTION MANUAL
F20-3090-14 INSULATOR SHEET
F20-3096-04 INSULATOR SHEET
H25-0858-04 VINYL COVER
H53-0335-04 CARTON BOX
J21-9101-04 BRACKET
J59-0403-05 NYLON RIVET
N67-3008-41 SCREW, SEMS PAN HD (M3✽8)
X72-1540-02 INTERFACE UNIT
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
Parts No.
IF-40GU (Y87-4020-00)
IF-40RS (Y87-4030-00)
IF-40USB (Y87-4140-00)
