TK-3170
34
PARTS LIST
R645,646 RK73GB1J271J CHIP R 270 J 1/16W
R647 R92-1252-05 CHIP R 0 OHM J 1/16W
R648 R92-1368-05 CHIP R 0 OHM
R701 RK73HB1J103J CHIP R 10K J 1/16W
R702,703 RK73HB1J472J CHIP R 4.7K J 1/16W
R704 RK73HB1J224J CHIP R 220K J 1/16W
R705,706 RK73HB1J472J CHIP R 4.7K J 1/16W
R707 RK73HB1J101J CHIP R 100 J 1/16W
R708 RK73HB1J103J CHIP R 10K J 1/16W
R710 RK73HB1J102J CHIP R 1.0K J 1/16W
R711 RK73HB1J474J CHIP R 470K J 1/16W
R713 RK73HB1J334J CHIP R 330K J 1/16W
R715,716 RK73HB1J332J CHIP R 3.3K J 1/16W
R717 RK73HB1J272J CHIP R 2.7K J 1/16W
R718 RK73HB1J100J CHIP R 10 J 1/16W
R719 RK73HB1J332J CHIP R 3.3K J 1/16W
R721 RK73HB1J224J CHIP R 220K J 1/16W
R722 RK73HB1J101J CHIP R 100 J 1/16W
R726 RK73HB1J474J CHIP R 470K J 1/16W
R727 RK73HB1J681J CHIP R 680 J 1/16W
R728 RK73HB1J221J CHIP R 220 J 1/16W X2
R728 RK73HB1J331J CHIP R 330 J 1/16W E
R729 RK73HB1J470J CHIP R 47 J 1/16W
R730 RK73HB1J472J CHIP R 4.7K J 1/16W
R732 RK73HB1J331J CHIP R 330 J 1/16W X2
R732 RK73HB1J391J CHIP R 390 J 1/16W E
R733 R92-1368-05 CHIP R 0 OHM E
R734 RK73HB1J104J CHIP R 100K J 1/16W X2
R734 RK73HB1J563J CHIP R 56K J 1/16W E
R735 RK73HB1J104J CHIP R 100K J 1/16W E
R735 RK73HB1J184J CHIP R 180K J 1/16W X2
R736 RK73HB1J104J CHIP R 100K J 1/16W X2
R736 RK73HB1J563J CHIP R 56K J 1/16W E
R737 RK73HB1J104J CHIP R 100K J 1/16W E
R737 RK73HB1J184J CHIP R 180K J 1/16W X2
R738 RK73HB1J120J CHIP R 12 J 1/16W E
R738 RK73HB1J4R7J CHIP R 4.7 J 1/16W X2
R739-741 RK73HB1J105J CHIP R 1.0M J 1/16W
R742 RK73HB1J222J CHIP R 2.2K J 1/16W X2
R743 RK73HB1J220J CHIP R 22 J 1/16W E
R743 R92-1368-05 CHIP R 0 OHM X2
R744 RK73HB1J221J CHIP R 220 J 1/16W E
R744 RK73HB1J391J CHIP R 390 J 1/16W X2
R747 RK73HB1J104J CHIP R 100K J 1/16W
R748 RK73HB1J824J CHIP R 820K J 1/16W X2
R750 RK73HB1J104J CHIP R 100K J 1/16W
R751 RK73HB1J154J CHIP R 150K J 1/16W X2
R751 RK73HB1J683J CHIP R 68K J 1/16W E
R752,753 R92-1368-05 CHIP R 0 OHM X2
R753 R92-1368-05 CHIP R 0 OHM E
R754,755 RK73HB1J105J CHIP R 1.0M J 1/16W
R756 R92-0670-05 CHIP R 0 OHM
R757 RK73HB1J105J CHIP R 1.0M J 1/16W
R758 R92-1368-05 CHIP R 0 OHM
R759 R92-1252-05 CHIP R 0 OHM J 1/16W
R760 R92-1368-05 CHIP R 0 OHM
R903 RK73HB1J102J CHIP R 1.0K J 1/16W
R913-916 RK73HB1J102J CHIP R 1.0K J 1/16W
R923 R92-1252-05 CHIP R 0 OHM J 1/16W
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-701X-XX)
S1 S70-0424-05 TACT SWITCH
S2 S70-0457-05 TACT SWITCH
S3,4 S70-0424-05 TACT SWITCH
D1 RB521S-30 DIODE
D4 MA2S111 DIODE
D16,17 MA2S111 DIODE
D24-27 MA2S111 DIODE
D28-31 RB706F-40 DIODE
D32 DA221 DIODE
D33 AVRM1608270MAB VARISTOR
D501 MA2S077 DIODE
D502,503 HSC277 DIODE
D505 1SV325F VARIABLE CAPACITANCE DIODE
D507 1SV325F VARIABLE CAPACITANCE DIODE
D509 1SV325F VARIABLE CAPACITANCE DIODE
D511 1SV325F VARIABLE CAPACITANCE DIODE
D513 ✽ 1SV278F VARIABLE CAPACITANCE DIODE
D514-516 HSC277 DIODE
D517 MA2S077 DIODE
D601 UDZS4.7B ZENER DIODE
D604-606 HVC131 DIODE
D608 HVC131 DIODE
D701,702 DAN235E DIODE
D703-707 HVC355B VARIABLE CAPACITANCE DIODE E
D703-708 HVC355B VARIABLE CAPACITANCE DIODE X2
D708 HVC350B VARIABLE CAPACITANCE DIODE E
D901 1SR154-400 DIODE
IC1 ✽ XC61CC5002NR MOS-IC
IC2 XC6204B502PR MOS-IC
IC3 ✽ XC61CN3402NR MOS-IC
IC4,5 BU4094BCFV MOS-IC
IC6 LC75834W MOS-IC
IC7 ✽ 30625MGP234HU MICROPROCESSOR IC
IC8 AT29C040A-90TU ROM IC
IC9 CAT24WC64WI ROM IC
IC10-12 ✽ TK62012F MOS-IC
IC13 AQUA-L MOS-IC
IC14 TC7W53FK(F) MOS-IC
IC15 ✽ TK62012F MOS-IC
IC16 M62364FP-F MOS-IC
IC17 ✽ TK62012F MOS-IC
IC18 TA7368F MOS-IC
IC19 TC75S51FE(F) MOS-IC
IC501 ADF4111BCP7 MOS-IC
IC601 TA75W01FUF MOS-IC
IC701 TA31136FNG MOS-IC
Q1 UMG3N TRANSISTOR
Q4 FP210 TRANSISTOR
Q5 UPA672T FET
Q6 UMG3N TRANSISTOR
Q7 UPA672T FET
Q8 DTA114EE DIGITAL TRANSISTOR
Q9 ✽ SSM6J08FU(F) FET
Q12 2SC4617(S) TRANSISTOR
Q13 2SB1132(Q,R) TRANSISTOR
Q14,15 ✽ SSM3K15TE(F) FET
Q16 2SA1774(S) TRANSISTOR
Q17 2SC4649(N,P) TRANSISTOR
Q19 ✽ SSM3K15TE(F) FET
To Next Page
