Kenwood TK-3170 E - Page 35

TK-3170
35
PARTS LIST
Q21 RN4910(F) TRANSISTOR
Q22 ✽ SSM3K15TE(F) FET
Q23 DTC144EE DIGITAL TRANSISTOR
Q24 ✽ SSM6J08FU(F) FET
Q25 2SK1830F FET
Q26 2SJ347F FET
Q27 DTC144EE DIGITAL TRANSISTOR
Q28 ✽ SSM3K01T(F) FET
Q29 ✽ SSM3K15TE(F) FET
Q30 2SJ243 FET
Q31,32 2SC4649(N,P) TRANSISTOR
Q33 2SJ347F FET
Q34 ✽ SSM3K15TE(F) FET
Q35 ✽ SSM3K01T(F) FET
Q501 2SC5488 TRANSISTOR
Q502,503 2SK508NV(K52) FET
Q504 ✽ SSM6P05FU(F) FET
Q505 2SC4617(S) TRANSISTOR
Q506,507 2SC5488 TRANSISTOR
Q601 2SC5488 TRANSISTOR
Q602 2SK3077F FET
Q603 RD01MUS1 FET
Q604 2SK3476 FET
Q605 DTC114EE DIGITAL TRANSISTOR
Q606 2SK879(GR) FET
Q607 DTC114EE DIGITAL TRANSISTOR
Q608 DTA144EE DIGITAL TRANSISTOR
Q609 ✽ SSM3K15TE(F) FET
Q701 2SC4649(N,P) TRANSISTOR
Q702 DTA144EE DIGITAL TRANSISTOR
Q703 2SC4649(N,P) TRANSISTOR
Q704 3SK318 FET X2
Q704,705 3SK318 FET E
Q705 3SK293 FET X2
TH501 B57331V2104J THERMISTOR
TH701,702 B57331V2104J THERMISTOR
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-701X-XX)
