Kenwood TM-D700A Service Manual

Receiver section
ADJUSTMENT
TM-D700A/E
Item
Measurement
Adjustment
Condition
Test-
equipment Unit | Terminal
Unit
Parts
Method
Specifications/
remarks
2. Sensitivity
check
[Wide]
4) Band B (Sub band)
FREQ.:146.050MHz:K
FREQ.:145.050MHz:
M4,E
SSG:0.398LV
(-115dBm):K
$SG:0.28uV (-118dBm):
M4,E
AF output:0.63V/80
[Narrow]
(E type only)
5) Band A
FREQ.:145.050MHz:E
$SG:0.22uV (-120dBm)
AF output:0.63V/8Q
6) Band B
FREQ.:435.150MHz:E
$SG:0.22uV (-120dBm)
AF output:0.63V/8Q
7) Band A (Sub band)
FREQ.:435.150MHz:E
SSG:0.35V (-116dBm)
AF output:0.63V/8Q
8) Band B (Sub band)
FREQ.:145.050MHz:E
SSG:0.35uV (-116dBm)
AF output:0.63V/8Q
SSG Rear ANT
Distortion | panel EXT.SP
meter
Oscilloscope
AF V.M
Check
SINAD 12dB or more
3. Squelch
write
Switch to adjustment
mode and carry out the
operations for Item A.
1) Band A
FREQ.:146.050MHz:K
FREQ.:145.050MHz:
M4,E
$SG:0.126uV
(-125dBm):K
$SG:0.112nV
(-126dBm):M4,E
SSG Rear ANT
panel EXT.SP
2) Band B
FREQ.:444,150MHz:K
FREQ.:435.150MHz:
M4,E
$SG:0.112pV
(-126dBm)
Display
[SET] key
Write
4. Squeich check
1) Band A
FREQ.:146.050MHz:K
FREQ.:145.050MHz:
M4,E
SSG:OFF
Set to the point where
noise will be erased by
turning the squeich
SSG Rear ANT
Oscilloscope] panel EXT.SP
knob.
Display
Check
Knob positi»n:
8:00 ~ 11:00
Busy lights off.
