- 49 - KFB-TM/KFN-TM-SH-e-1410
13.2 Parts List
No
Parts Name
Qty
Spec
1
Key Panel
1
2
Display Protection Plate
1
3
Front Cover
1
4
Main PCBA
1
5
Insulation Washer
9
6
Self Thread Screw
10
3x10
7
Washer
4
8
Battery bar
2
9
Battery
1
6V/1.2AH
10
Self Thread Screw
2
M3
11
Nut
3
M3, Hexagon
12
RS-232 port
1
13
D Connecter
1
14
Star (+) Screw
1
3Mx20
15
Branch pipe
1
16
Main Serial board
1
17
Interface Module
1
18
Back Cover
1
19
Air Connecter
1
20
Star (+) Screw
7
M4x16
