KERN KFB-TM Service Manual

- 51 - KFB-TM/KFN-TM-SH-e-1410
13.4 Parts List
No
Parts
Qty
Spec
1
Key Panel
1
2
Front Cover
1
3
Display Protection Plate
1
4
Nut
6
M3*6
5
Main PCBA
1
6
Washer
6
8x3.1x1.5
7
Star (+) Self Thread screw
6
M3x8
8
Water Proof Rubber Bar
1
9
Star (+) Screw
2
M4x10
10
Washer
2
M4
11
Battery Clamp
1
12
Washer
6
M4
13
Star (+) Big head Screw
6
M4x12
14
Bracket
1
15
Bracket Screw
2
16
Water Proof Adaptor jack
1
17
Interface Module
1
18
Air connecter
1
5Pin
19
Plug
1
20
Rubber Spacer
3
21
Air Connecter
1
7Pin
22
Back Cover
1
23
Air Connecter Water Proof Nut
1
24
Battery
1
6V/4Ah
25
Nut
1
M3x6
26
Main Serial board
1

KERN KFB-TM Specifications

General

Brand	KERN
Model	KFB-TM
Category	Monitor
Language	English
