Flue Sleeve
Flue Pipe
Flue
Terminal
Flexible
Wall
Seal
Wall
Plate
Flue Sleeve Flange
2.13 FITTING THE FLUE SLEEVE
1. Cut hole in wall.
2. Measure wall Thickness
3. Cut sleeve length to match wall thickness & remove burrs.
4. Grout sleeve into wall with ange on external face.
5. Slide ue pipe into sleeve, checking it is free to slide.
6. Slide Flexible wall seal over ue pipe and push centre ring
up to sleeve ange when cold.
7. Locate wall plate over exible wall seal and clamp in place
using the raw plug pack.
8. Afx ue terminal
9. During boiler test check that the ue end is free to expand
and contract with exible wall seal.
