Keurig B3000 - Control Panel and Main PCB

B3000 SERVICE MANUAL
60-200807-000, REV C 30
E. Cold Water Pump – located at the lower right rear of brewer:
F. Control Panel – located on the front of brewer:
COLD WATER PUMPS
PLATE
VIBRATION ISOLATORS
LCD / PCB COVER
LCD DISPLAY
CONTROL
BUTTONS
PRESSURE
TRANSDUCER
TUBE /
CONNECTO
R
