B3000 SERVICE MANUAL
60-200807-000, REV C 64
6. Sanitizing / Cleaning the Puncture Mechanism (P.M.)
A. Sanitizing/Cleaning the B3000 Inlet Needle and Gasket
FOR PROPER SANITIZING / CLEANING OF
THE PUNCTURE MECHANISM, THE
FOLLOWING ITEMS ARE RECOMMENDED.
A. DISHWASHING LIQUID SOLUTION OR
SOAP & WATER IN A SPRAY BOTTLE.
B. MINI SCRUB BRUSH FOR CRAMPED AND
TIGHT AREAS [i.e. AS SHOWN, McMASTER-
CARR PT NO. 7243T22].
C. CLOTH FOR WIPING.
D. ACCESS TO A SINK (IDEALLY WITH FRUIT
SPRAYER) OR A BUCKET OF WATER FOR
RINSING. SEE IMAGES 18 AND 19.
C
1. DEPRESS NEEDLE
PLATFORM TO EXPOSE
INLET NEEDLE AND THE
INLET NEEDLE GASKET.
LOOK FOR TEARS OR
OTHER NON FUNCTIONING
CONDITIONS.
2. WHILE DEPRESSING
THE PLATFORM
REMOVE STUBBORN
PARTICLES BY USING
BRUSH AND WATER.
3. WIPE THE NEEDLE AND
GASKET AREA CLEAN
USING A DRY CLOTH.
PERFORM THREE
CLEANSING BREWS
(BREWS WITHOUT K-
CUPS) TO RINSE OUT
NEEDLE.
To Next Page
