B3000 SERVICE MANUAL
60-200807-000, REV C 32
J. MAIN PCB – located on the left side looking at the front of brewer:
HOT WATER VALVE
CONNECTOR
MAIN POWER
HARNESS
CONNECTOR
MAIN HARNESS
CONNECTOR
SOFTWARE VERSION
NUMBER
