Keurig B3000 Service Manual

B3000 SERVICE MANUAL
60-200807-000, REV C 33
2. REPLACEMENT PART NUMBERS
POWER MODULE 16-200904-000
K-CUP PUNCTURE MODULE 16-200905-000
HOT WATER TANK MODULE 16-200906-000
COLD WATER TANK MODULE 16-200907-000
COLD WATER PUMP MODULE 16-200908-000
CONTROL PANEL MODULE 16-200914-000
FRONT DOOR MODULE 16-200909-000
MAIN HARNESS MODULE 16-200910-000
BIN SENSOR MODULE (Included in Main Harness Module) USE 16-200910-000
DRIP TRAY MODULE 16-200912-000
MAIN PCB MODULE 16-200913-000
HOT WATER DISPENSE VALVE ASSEMBLY 16-200894-000
K-CUP HOLDER ASSEMBLY 16-200936-000
INLET VALVE FILTER 01-201200-000
LOCKSET COIN MECH B3000 16-200962-000
CHUTE B3000 16-200951-000
INLET WATER VALVE B3000 16-200959-000
DISPOSAL BIN 16-200969-000
BASE PLATE MODULE 16-200938-000
CLAMP, HOSE, 14.81MM ID x 7.92MMW, SPRING STL 04-200819-000
CLAMP, HOSE, 9.53MM ID X 7.92MM W, SPRING STL 04-200685-000
CLAMP, HOSE, 12.45MM ID X 7.94MM W, SPRING STL 04-200872-000
CLAMP, HOSE, 13.21MM ID X 7.92MM W, SPRING STL 04-200684-000
CLAMP, HOSE, 8.51 MM ID X 7.92 MM W, SPRING STL 04-200880-000
CLAMP, HOSE, 6.1MM ID X 6.35 MM W, SPRING STL 04-200873-000
ENTRANCE NEEDLE ASSEMBLY (ENA) 16-200993-000
K-CUP HOLDER PIVOT 16-200995-000
ENTRANCE NEEDLE GASKET, SN ABOVE 7506 16-200997-000

Keurig B3000 Specifications

General

Voltage	120 V
Brew Time	Under 1 minute
Compatible Pods	K-Cup pods
Brew Sizes	6, 8, 10, 12 oz
Display	LCD
Color	Black
