Keurig B3000 - Page 47

B3000 SERVICE MANUAL
60-200807-000, REV C 47
3. Disconnect the Hot Water Valve hose from the top of the bottom tank.
4. Locate the two screws at the top of the module. Loosen them fully. These are captive screws so
they will NOT come out completely.
5. Tilt the module toward you. It is secured on the bottom with mounting tabs. Lift the module out
carefully.
