B3000 SERVICE MANUAL
60-200807-000, REV C 50
4. Remove RED retaining clip from Murdock fitting. This is a quick release tube connection. Push
in on the collar, and pull out the tube.
5. Release clamp and disconnect the hose on the LEFT side of the top Hot Water Tank.
6. Disconnect the hoses on the top of each of the water pumps.
7. Disconnect the Cold Water Tank drain hose on the bottom right side of the tank.
