B3000 SERVICE MANUAL
60-200807-000, REV C 55
5. Disconnect the small tube at the union connection.
6. Disconnect the wire harness connection.
7. The Control Panel Module can now be removed.
8. Install the new module and connect all of the appropriate connections, hoses, and wires making
sure that they are secure and tight.
9. Conduct a BIT test (see appendix VII on page 85) to insure the proper function of the brewer.
