4.4 - Learning a transmitter
A transmitter can be “learned” via the specic programming menu or
by remote memorisation, using a previously memorised transmitter.
MEMORISING A REMOTE CONTROL
If you are in programming mode exit pressing the MENU button until -- appears. Press the DOWN (RADIO)
button for more than 2 seconds. Until the display shows the word “rad” (radio), then release the button
1. Press and release the DOWN (RADIO) button a number of times equal to the number of the output to be acti-
vated: once for output STEP BY STEP, twice for output PEDESTRIAN, three times for output ONLY OPEN, four
times for output LIGHT ON/OFF, ve times for output PRESET (button 1 = output 1, button 2 = output 2, button
3 = output 3, button 4 = output 4)
+ +
2. The KEY LED will ash a number of times equal to the number of the output selected, with 1 second pauses
between ashes
+1s +1s
3. Press the key of the remote control to be memorised within 7 seconds, holding it down for at least 2 seconds
2s
4. If the memorisation has been successful, the KEY LED will give one long ash
3s
5. To memorise another remote control on the same output, repeat point 3
N.B If no commands are given for 7 seconds, the receiver automatically quits the programming mode
DELETING A REMOTE CONTROL
If you are in programming mode exit pressing the MENU button until -- appears. Press the DOWN (RADIO)
button for more than 2 seconds. Until the display shows the word “rad” (radio), then release the button
1. Press the DOWN (RADIO) button until the LED lights up (about 3 seconds)
2. Press the key of the remote control to be deleted within 7 seconds, holding it down until the KEY LED goes
out. Release the remote control key
(>3s)->
3. About 1 second after the key is released, the KEY LED starts to ash
->
4. Conrm the deletion by pressing the DOWN (RADIO) button
0,5s 0,5s
5. If the deletion has been successful, KEY LED will give one long ash
N.B If no commands are given for 7 seconds, the receiver automatically quits the programming mode
3s
REMOTE MEMORISATION OF A REMOTE CONTROL WITH A REMOTE CONTROL ALREADY MEMORISED
A transmitter can be memorised without accessing the receiver. The user needs to have a transmitter memorised
previously, after which the procedure is as described below. The remote copy procedure must be carried out in
the area served by the receiver.
1. Press the key of the new remote control to be memorised, holding it down for at least 5 seconds
>5s
2. Press the key of the old remote control to be copied (if phase 1 has been successful, the automation system
will not respond)
>3s
3. Press the key of the new remote control to be memorised, holding it down for at least 3 seconds
>3s
4. Press the key of the old remote control to be copied, holding it down for at least 3 seconds, to conrm and quit
the programming mode
>3s
N.B If no commands are given for 7 seconds, the receiver automatically quits the programming mode
CLEARING THE ENTIRE RECEIVER MEMORY
If you are in programming mode exit pressing the MENU button until -- appears. Press the DOWN (RADIO)
button for more than 2 seconds. Until the display shows the word “rad” (radio), then release the button
1. Press the DOWN (RADIO) button and hold it down until the LED lights up (about 3 seconds) and then goes
out (about 3 seconds). Release the key
(>3s)-> (>3s)->
2. About 1 second after the key is released, the KEY LED starts to ash
(1s)+ (1s)+
3. Press the key on the receiver as the LED ashes for the third time
4. If the deletion has been successful, the KEY LED will give one long ash
3s
