Keysight 34980A Service Guide 15
Scan
– Set up trigger-in parameters
– Set up sweep count
– Set up sample count
Sequence
– View sequence command string
– Execute sequence
– Delete sequence definitions
Module
– Open all relays
– Clear all measurement functions
– Clear channel labels
– Configure external trigger and clock (34951A)
– Set trace or level mode (34951A)
– Set waveform parameters (34951A)
View
– View errors and alarms
Advanced
Available at a later firmware release
Alarm
– Select one of four alarms to report alarm conditions on the displayed channel
– Configure a high limit, a low limit, or both for the displayed channel
– Select the slope (rising or falling edge) for the four alarm output lines
