3 Calibration Procedures
62 Keysight 34980A Service Guide
34952A Verification
Analog Output Verification Test
This procedure is used to check the
calibration of the analog outputs on the 34952A Multifunction Module.
Verification checks are performed only for those output values with unique
calibration constants.
1 Use the internal DMM to measure the output of each channel. You will need to
physically move the input connections on the 34952A module to channel 6
and then channel 7.
2 For each analog output (channel 6 and channel 7), set each output value in the
table on the next page. Compare measurement results to the appropriate test
limits shown in the table.
It is not necessary to test the voltage output at the full rated 10 mA load.
Output Voltage Quick Check Error from Nominal (1 year)
10 V Q ± 45 mV
0 V Q ± 20 mV
-10 V ± 45 mV
