8 Keysight 34980A Service Guide
3 Store/recall menu allows you to save and recall up to six instrument setups
4 Control keys directly control module actions
5 Number keypad enters numerical characters
6 Exponent
7 Cancel key exits a menu without saving changes
8 Arrow keys move cursor positions
9 Knob enters alphanumeric characters, selects slots, channels, and navigates menus
10 Enter key steps you through a menu or saves number entries
11 Running a program puts the display into “remote” and disables the front panel keys. Local takes you out
of “remote” mode and enables the front panel keys.
12 Configure keys select functions and set function parameters
13 Measure keys execute and monitor measurements. Depending on which measurement key you use, you
can have complete/direct control over the switching and measurement operation, or you can have the
34980A automatically control these to capture the desired data.
For proper instrument function, Channel monitor must be
turned OFF when the state is stored and Auto recall is
enabled. If the Channel monitor is turned ON, the front
panel may freeze, If the front panel is frozen, all plug-in
modules must be removed and the auto-recall function
turned OFF to restore the instrument back to its initial
working state.
