8163A/B, 8164A/B & 8166A/B Mainframes Programming Guide 259
The Keysight 816x VXIplug&play Instrument Driver 7
Figure 10 Advanced Device Configuration - Plug&play Driver
5 Select hp816X from the Plug&play Driver Name drop-down list.
If you do not see this driver in the list, the driver has not installed properly.
6 Enter the Parameters to the init() call by entering GPIB::xx::INSTR
where xx is your instrument’s GPIB address.
7 Select whether to Perform Reset or to Perform Identification Query
whenever Keysight VEE opens the instrument for interaction.
8 Confirm the selections pressing the OK button.
9 Return to the Instrument Manager screen and press the Save Config to
save the configuration.
If you do not see this driver in the list, the driver has not installed properly.
20 is the default GPIB address for your instrument.
