288 8163A/B, 8164A/B & 8166A/B Mainframes Programming Guide
8 GPIB Command Compatibility List
Error Handling
Most error commands and error texts for all instruments are new.
The HP 8153A timed out for every error. Errors are handled differently by
the 8163A/B and 8164A/B; instead of timing out for every error, special
values are returned for erroneous queries. Table 16 on page -288 and
Table 17 on page -288 detail the new errors
The error queue is written to as before.
Table 16 Error Handling Changes
Table 17 Specific Errors
Command Order
It is not yet known if there are any changes in the command order
behavior.
Expected Return Value Returned Value Affects
FLOAT(32/64) FLT/DBL_MAX 8153
(U)INT(16/32) (U)INT(16/32)_MAX 8153
Block " " 8153
Boolean Value 0 8153
Enum Time out 8153
Command Change Affects
FETCh:POWer? - without using a
preceding trigger
Returns the last valid value instead of timing out.
No error is generated.
8153
