8163A/B, 8164A/B & 8166A/B Mainframes Programming Guide 217
Measurement Operations & Settings 4
Extended Trigger Configuration
This section includes information for advanced users about how to
customize your use of the trigger system.
You can configure the ouputs and inputs from two nodes, Node A and
Node B. See <Cross Reference Color>Figure 7on page 219 for more
information on Node A and Node B. You can configure these nodes to be
triggered by certain events and for these nodes to trigger particular
actions.
command: :TRIGger
syntax: :TRIGger<wsp>NODEA|1|NODEB|2
description: Generates a hardware trigger.
parameters: 1 or NODEA:
2 or NODEB:
Generates trigger at Node A.
Generates trigger at Node B.
Use :TRIGger:CONF:EXTended on page 217 to configure Node A and Node B.
:TRIGger on page 209 describes the :TRIGger command for basic users.
response: none
example: trig 1
command: :TRIGger:CONF:EXTended
syntax: :TRIGger:CONF:EXTended<wsp><Node A Input Config.>,
<Node B Input Config.>,<Output Matrix Config.>
description: Sets the extended hardware trigger configuration.
parameters: Node A Input Configuration:
Node B Input Configuration:
Output Matrix Configuration:
A 32-bit unsigned integer, see below.
A 32-bit unsigned integer, see below.
A 32-bit unsigned integer, see below.
response: none
example: trig:conf:ext 0,0,0
command: :TRIGger:CONF:EXTended?
syntax: :TRIGger:CONF:EXTended?
description: Returns the extended hardware trigger configuration.
