8163A/B, 8164A/B & 8166A/B Mainframes Programming Guide 9
Introduction to Programming 1
Table 1 GPIB Capabilities
Setting the GPIB Address
There are two ways to set the GPIB address:
• You can set the GPIB address by using the command
:SYSTem:COMMunicate:GPIB[:SELF]:ADDRess on page 71.
• You can set the GPIB address from the front panel. See your
instrument’s User’s Guide for more information.
The default GPIB address is 20.
Mnemonic Function
SH1 Complete source handshake capability
AH1 Complete acceptor handshake capability
T6 Basic talker; serial poll; no talk only mode; unaddressed to talk if addressed to listen
L4 Basic listener; no listen only mode; unaddressed to listen if addressed to talk
SR0 No service request capability
RL1 Complete remote/local capability
PP0 No parallel poll capability
DC1 Complete device clear capability
DT0 No device trigger capability
C0 No controller capability.
GPIB address 21 is often applied to the GPIB controller. If so, 21 cannot be used
as an instrument address.
