17 | Keysight | B1500A Semiconductor Device Analyzer - Configuration Guide
WGFMU Accessories
Model/Option Description Contents Qty Additional Information
16493R - - Order with the option.
WGFMU to RSU cable length option
16493R-001 WGFMU to RSU cable (0.6 m) WGFMU to RSU cable 1
16493R-002 WGFMU to RSU cable (2.4 m)
16493R-003 WGFMU to RSU cable (3 m)
16493R-004 WGFMU to RSU cable (5 m)
16493R-005 WGFMU to RSU cable (4.4 m)
16493R-006 WGFMU to RSU cable (1.5 m)
Cable option for connection with DC probe
16493R-101 SSMC short-open cable for current
return path (50 mm)
SSMC short-open cable 1
16493R-102 SSMC short-open cable for current
return path (75 mm)
16493R-103 SMA-SSMC cable between RSU and
DC probe (200 mm)
SMA-SSMC cable 1
Cable option for connection with RF probe
16493R-302 SMA-SMA cable between RSU and RF
probe (200 mm)
SMA-SMA cable 1
Other WGFMU accessories
16493R-801 WGFMU connection adapter
(female-female)
connection adapter 1 This can be used for a shield box to hook up the RSU
cable.
16493R-802 Magnet stand for RSU (1 ea) Magnet stand 1 Two stands are required for one WGFMU.
16493R-803 Sync terminal connection cable Sync cable 1
