07 | Keysight | B1500A Semiconductor Device Analyzer - Configuration Guide
B1500A Configuration Options and Contents, continued
Model/Option Description Contents Qty Additional Information
Select add-on packages (optional) - continued
B1500A-A25 Add-on Package - Pulse
Generator Unit (B1525A) 1ea,
Cables
HV-SPGU 1 Installed HV-SPGU module
SPGU cable 2 SPGU Cable (SMA to Coaxial)
SPGU synchronous
cable
2 SPGU synchronous cable (16493Q, SMA to SMA, 8 cm).
B1500A-A28 Add-on Package - Atto Sense
Unit 1ea for High Resolution
Source Monitor Unit
ASU 1 Atto sense switch unit (E5288A ASU), 1 ea.
Triaxial and D-sub
cable for ASU
1 A set of triaxial D-sub Cable for ASU (16493M).
Cable length is 1.5 m or 3.0 m
B1500A-A29 Add-on Package - Atto Sense
Unit 1ea, for Mid Power Source
Monitor Unit (only for B1511B)
ASU 1 Atto sense switch unit (E5288A ASU), 1 ea.
Triaxial and D-sub
cable
1 A set of triaxial D-sub Cable for ASU (16493M).
Cable length is 1.5 m or 3.0 m
B1500A-A30 Add-on Package - B1530A 1ea,
Remote Sense Unit 2ea, Cables
WGFMU 1 Installed WGFMU module
RSU 2 Remote-sense and switch unit (RSU)
RSU cable 2 RSU cable between WGFMU and RSU.
Cable length is 1.5 m or 3.0 m
