20 | Keysight | B1500A Semiconductor Device Analyzer - Configuration Guide
Other Accessories, continued
Interlock cable and accessory
Model/Option Description Contents Qty Additional Information
16493J Interlock cable - - Order with the option.
Select cable length option
16493J-001 Interlock cable (1.5 m) Interlock cable 1
16493J-002 Interlock cable (3 m) Interlock cable 1
16493J-003 Interlock cable (5 m) Interlock cable 1
Model/Option Description Contents Qty Additional Information
N1254A Accessories for instruments and fixtures - - Order with the options.
Select cable length option
N1254A-402 Interlock micro switch Switch 1 Interlock micro switch (3101-4439)
Digital I/O cable and accessories
Model/Option Description Contents Qty Additional Information
16493G Digital I/O control cable - - Order with the option.
Select cable length option
16493G-001 Digital I/O control cable, (1.5 m) Control cable 1
16493G-002 Digital I/O control cable, (3 m) Control cable 1
Model/Option Description Contents Qty Additional Information
N1253A Digital I/O accessories - - Order with the option.
Select cable length option
N1253A-100 Digital I/O T-cable Digital I/O T-cable 1 Digital I/O T-cable has 2 male and 1 female
connectors in order to connect more than two
units. In order to connect three units, order one
N1253A-100 and one 16493G cable.
N1253A-200 Digital I/O BNC box Digital I/O BNC box 1 Adapter for connecting Digital I/O port with
BNC trigger port of other instruments. Box
which has 8 BNC connectors for connecting
with BNC trigger port of other instruments
and 25 pin D-sub connector for connecting
this box to B1500A. In order to use this box for
connection, need D-sub 25 pin straight cable
(16493G) and BNC cable.
