08 | Keysight | B1500A Semiconductor Device Analyzer - Configuration Guide
B1500A Configuration Options and Contents, continued
Model/Option Description Contents Qty Additional Information
Select add-on packages (optional) - continued
B1500A-A31 Add-on Package - B1530A 1ea,
Connector Adaptor, Remote
Sense Unit 2ea, Cables
WGFMU 1 Installed WGFMU module
RSU 2 Remote-sense and switch unit (RSU)
RSU cable (2.4 m) 2 RSU cable (2.4 m) between WGFMU and connector adapter.
Cable length can’t be selected by option 015/030.
RSU cable (0.6 m) 2 RSU cable (0.6 m) between connector adapter and RSU.
Cable length can’t be selected by option 015/030.
Connector adapter 2 Connector adapter for RSU cable, female - female (16493R-801).
This can be used for a shield box to hook up the RSU cable.
B1500A-A3P Add-on Package - Probe cable
kit for B1530A(8 probe cables.
B1530A not included)
SSMC cable,
50 mm
2 SSMC short-open cable for current return path, 50 mm (16493R-101)
SSMC cable,
75 mm
2 SSMC short-open cable for current return path, 75 mm (16493R-102)
SMA-SSMC cable,
200 Mm
2 SMA-SSMC cable between RSU and DC probe, 200 mm (16493R-202)
SMA cable,
200 mm
2 SMA-SMA cable between RSU and RF probe, 200 mm (16493R-302)
