7) Press , , , and then press to open the DIO Conguration dialogue.
8) Press and select to specify the Digital I/O pin number; the properties of this pin is
what we will congure.
9) Rotate to select Input/output function and press to edit it. Then press to set
it to Trigger input.
10) Rotate to select Polarity and press to edit it. Then press to set it to
Positive polarity.
11) Press to save the changes.
(1) Press More...
(2) Press I/O
(3) Press DIO
(4) Press Cong
