2 Verification and Adjustments
54 Keysight E36200 Series Service Guide
Performance Verification
Performance verification ensures that the instrument performs within the
specifications stated in its data sheet (http://literature.cdn.keysight.com/litweb/
pdf/5992-3747EN.pdf.)
Recommended test equipment
The test equipments recommended for the performance verification and
adjustment procedures are listed below. If the exact instrument is not available,
use the accuracy requirements shown to select substitute calibration standards.
Type Specification Recommended model
Digital multimeter
Readout: 6 ½ digits
Basic DC accuracy: 0.0035%
Keysight 34465A or equivalent
Current monitor 50 A (0.05 Ω), TC = 4 ppm/°C Guildline 9230A-50
Electronic load
150 V, 20 A minimum, with transient capability
and a slew rate of 833 kA/s or better
Keysight N3300A mainframe, with
N330xA modules
Fixed load
Wirewound resistor 1000 W, 40 Ω
E36232A and E36234A output: 18 Ω
DSR-1000W40RJ-F-V1
Wirewound resistor 1000 W, 10 Ω
E36231A and E36233A output: 4.5 Ω
DSR-1000W10RJ-F-V1
Wirewound resistor 2000 W, 2.5 Ω
E36232A and E36234A output: 2 Ω
DSR-2000W2R5J-F-V1
Wirewound resistor 2000 W, 0.6 Ω
E36231A and E36233A output: 0.5 Ω
DSR-2000WR6J-F-V1
Oscilloscope
Sensitivity: 1 mV
Bandwidth limit: 20 MHz
Probe: 1:1 with RF tip
Keysight Infiniium/6054A or
equivalent
RMS voltmeter
True RMS
Bandwidth: 10 MHz
Sensitivity: 100 μV
Keysight 3458A or equivalent
Differential amplifier Bandwidth: 20 MHz LeCroy 1855A or equivalent
