Calibration procedure
Enter the calibration state
To begin the calibration procedure, you must enter the calibration state.
Calibrate voltage
Allow the unit to sit with its output turned ON for one minute, then connect the
DMM voltage input to the power supply.
Step Front panel SCPI
1
Press Utilities > Test / Setup > Calibration.
Enter the default passcode (default passcode is 0). Press Login to
enter the calibration page.
CAL:SEC:STAT 0, <code>
2 To change a forgotten passcode to a new passcode, you can turn on
the instrument after shorting the CAL SECURE jumper J10 on the
front panel board and sending the SCPI command shown on the
right to change the passcode.
CAL:SEC:CODE <new code>
Step Front panel SCPI
1
Press Perform Calibration. For E36233A and E36234A models,
select the channel for calibration.
Press Cal Volt.
CAL:VOLT:LEV MIN, (@<channel>)
2 Measure the output voltage (low point) with the DMM.
3 Enter the measured value, and press Next.
CAL:VOLT <reading>, (@<channel>)
CAL:VOLT:LEV MAX, (@<channel>)
4 Measure the output voltage (high point) with the DMM.
5 Enter the measured value, and press Next.
CAL:VOLT <reading>, (@<channel>)
6 Read DONE or FAIL on the display. (wait 30 seconds)
SYST:ERR?
7 Press Cal Save.
CAL:SAVE
To Next Page
