Disassembly
Tools required
Removing/Installing the optional GPIB interface
Refer to the E36200 Series User’s Guide for more information on how to remove or
install the optional GPIB interface (Chapter 1, “Product Information” >
Installation > Installing the optional GPIB interface).
Items Torque value
PZ1 driver 9.0 in.lbs
T10 Torx driver 9.0 in.lbs
T8 Torx driver 9.0 in.lbs
1/4" nut socket 9.0 in.lbs
1/2" nut socket 3.5 in.lbs
TURN OFF POWER AND REMOVE ALL CONNECTIONS BEFOREPROCEED
Turn off the power and remove all connections, including the power cord,
from the instrument prior installation/removal of the GPIB interface.
RETAIN GPIB COVER PLATE
After installing the GPIB interface, retain the cover plate for use in the event
that you ever remove the GPIB interface. The instrument should never be
connected to power or inputs on the output terminals without either the
GPIB interface or the cover plate securely covering the rear-panel opening.
