1 Getting Started
46 Keysight E364xA User’s and Service Guide
Use the front panel key to:
– Select the GPIB or RS-232 interface.
– Set the GPIB address.
– Set the RS-232 baud rate and parity.
Display annunciators
Figure 1-6 Display annunciators
Table 1-5 Rear panel overview
No Description
1AC inlet
2 Power-line fuse-holder assembly
3 Power-line module
4 RS-232 interface connector
5 GPIB (IEEE-488) interface connector
6Rear output terminals
