X-Series Signal Analyzers Getting Started and Troubleshooting Guide 35
Front and Rear Panel Features
Rear-Panel Features
Item
Description
# Name
1 EXT REF IN Input for an external frequency reference signal.
2 WIDEBAND DIGITAL BUS LVDS output for I and Q.
3 10 MHz OUT An output of the analyzer internal 10 MHz frequency reference that the analyzer is
currently using internally.
4 SNS Series Noise Source For use with Keysight N4000A, N4001A, N4002A Smart Noise Sources (SNS).
5 Noise Source Drive +28 V
(Pulsed)
For use with Keysight 346A, 346B, and 346C Noise Sources.
6 TRIGGER 1 IN Allows external triggering of measurements.
7 TRIGGER 2 IN Allows external triggering of measurements.
8 Sync Reserved for future use.
9 TRIGGER 1 OUT A trigger output used to synchronize other test equipment with the analyzer.
Configurable from the Input/Output keys.
10 TRIGGER 2 OUT A trigger output used to synchronize other test equipment with the analyzer.
Configurable from the Input/Output keys.
11 Analog Out For Option YAS:
Screen Video
For Option YAV:
Screen Video
Log Video
Linear Video
For Option EMC or N9063C or N9063EM0E Analog Demod Measurement
Application:
Demod Audio
12 Digital Bus Reserved for future use
13 Aux IF Out For Option CR3:
Second IF Out (UXA, PXA, MXA, and EXA)
For Option CRP:
Arbitrary IF Out (UXA, PXA, MXA, and EXA)
For Option ALV:
Log Video (UXA and PXA)
14 Line power input The AC power connection. See the product specifications for more details.
15 Removable Disk Drive Standard on all analyzers.
16 VGA Allows connection of an external VGA monitor.
