Installation Note N9030-90077 5
Option BBA, Analog Baseband I/Q Inputs Upgrade Kit
Installation Kit Parts List
Quantity Description Keysight Part Number
1 BBIQ Main Board N9020-60093
1 LED Board N9020-63095
1 BBIQ Interface Board N9020-60094
1 LED Board Overlay, Bottom N9020-80166
1 LED Board Overlay, Top N9020-80163
1
Cable, Flex Ribbon
a
a.Only needed when installing on N9030B
8121-2090
1
Cable, Flex Ribbon
b
b.Only needed when installing on N9020B
8121-1683
1 Option BBA Cable Kit (with wire markers) N9030-60018
1 Core Bracket, top N9020-00071
1 Core Bracket, bottom N9020-00072
60 Screws, M3 X 0.5 (8 mm long) 0515-0372
1 Vibration Mount 0460-2725
15 Screws, M3 X 0.5 (6 mm long), flat head 0515-1946
9 Screws, M3 X 0.5 (8 mm long), flat head 0515-2032
2 Screws, Hex Shoulder N9020-20017
2 Main Board Warning Labels N9020-80036
1 Entitlement Certificate 5964-5178
1 Entitlement Certificate Envelope 5967-7169
5 Tie Wrap 1400-0249
1 Installation Note This note
1 Probe tip BNC adapter 5063-2143
1 Cable 8120-2682
