Performance Verification Tests 4
Keysight 3458A Calibration Manual 79
PERFORMANCE TEST CARD - 1 YEAR LIMITS
Keysight Model 3458A Multimeter Serial number _________________________ Test performed by _________________________
Date _________________________
AC VOLTAGE TESTS
Perform an ACAL AC
Test # 3458A input 3458A range
Transfer
standard
read ing
Unit
under test
reading
Difference
Limit
(Std)
Limit
(Opt 002)
Pass Fail
1 100 mV, 1kHz 100 mV __________ __________ __________ 000.0250 mV 000.0250 mV __________ __________ 2 1 V, 1 kHz 1 V __________ __________ __________ 0.000250 V 0.000250 V __________ __________ 3 1 V, 1 kHz 10 V __________ __________ __________ 00.00096 V 00.00096 V __________ __________ 4 10 V, 20 Hz 10 V __________ __________ __________ 00.01338 V 00.01338 V __________ __________ 5 10 V, 1 kHz 10 V __________ __________ __________ 00.00250 V 00.00250 V __________ __________ 6 10 V, 20 kHz 10 V __________ __________ __________ 00.00272 V 00.00272 V __________ __________ 7 10 V, 100 kHz 10 V __________ __________ __________ 00.05372 V 00.05372 V __________ __________ 8 10 V, 1 MHz 10 V __________ __________ __________ 00.55450 V 00.55450 V __________ __________ 9 100 V, 1 kHz 100 V __________ __________ __________ 000.0364 V 000.0364 V __________ __________
10 700 V, 1 kHz 1000 V __________ __________ __________ 0000.544 V 0000.544 V __________ __________
