Keysight B1500A Series User Manual

1-6 Keysight B1500A Configuration and Connection Guide, Edition 6
B1500A Product Configuration
Options of B1500A series
1.2 Options of B1500A series
This section describes Option items of the Keysight B1500A Semiconductor Device
Analyzer.
Table 1-3 B1500A Options
Model/
Option
Description OP Instruction
Mainframe
B1500A Semiconductor device analyzer
mainframe
• Select option 015 or 030 to specify cable length.
• Select option 050 or 060 to specify Power line
frequency.
• The following accessories are included. See
Table 1-3, for more details of furnished
accessories.
Keyboard
USB mouse
Stylus pen
One Interlock cable (1.5 m or 3.0 m)
One GNDU cable (1.5 m or 3.0 m)
One Triaxial cable (1.5 m or 3.0 m)
GNDU to Kelvin adaptor
CD-ROM Manuals
Select standard packages (mandatory)
B1500A-A00 Empty package for custom solution • No module is included in B1500A mainframe
• Specify Add-on package option.
B1500A-A01 Standard pack 1 -Standard package
(Mid PWR unit 4ea, cables)
• Standard package-1 contains four MPSMU and
eight Triaxial cables.
• Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
B1500A-A02 Standard pack 2 -High resolution
package (High resolution unit 4ea,
cables)
• Standard package-2 contains four HRSMU and
eight triaxial cables.
• Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
B1500A-A03 Standard pack 3 -High power package
(High PWR unit 2ea, Mid PWR unit
2ea, cables)
• Standard package-3 contains two HPSMU, two
MPSMU, and eight triaxial cables.
• Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
B1500A-A04 Standard pack 4 - Flash pack (Mid
PWR unit 2ea, Hi-res unit 2ea, PGU,
accessories)
• Standard package-4 contains two MPSMU, two
HRSMU, one HVSPGU and accessories for
flash memory cell measurement See Table 1-8.
