Keysight B1500A Series - Flash Memory Cell Characterization (2 Pulse Channels)

4-22 Keysight B1500A Configuration and Connection Guide, Edition 6
Connection and Ordering Examples
Four terminal device
4.2.8 Flash memory cell characterization (2 pulse channels)
Figure 4-11 Configuration for flash memory cell characterization
MPSMU
Triaxial cable
Sense
Force
B1500A
MPSMU
Sense
Force
Interlock cable
HRSMU
Sense
Force
HRSMU
Sense
Force
HVSPGU
Channel 2
Channel 1
PGU 1
SMU 1 Output 1
16440A Selector
PGU 2
SMU 2 Output 2
Ctrl In
Ctrl Out
Ctrl In
Ctrl Out
16445A
Selector Adapter
Digital I/O cable
Control cable
SPGU cable
Triaxial cable
Digital I/O
Connector plate
Fixture/Prober
DUT
Interlock
Coverage of Configuration Example
G
D
Subs
S
