Keysight B1500A Series User Manual

4-16 Keysight B1500A Configuration and Connection Guide, Edition 6
Connection and Ordering Examples
Four terminal device
4.2.5 High power IV characterization
Figure 4-8 High power IV configuration
Table 4-22 Target device and application
Table 4-23 Key specification
Device Application Note
FET I
d
-V
d
, V
th
, BV
dss
, I
d
leak, I
g
leak
Item Range Note
Maximum I/V range 1 A / 200 V
Minimum I/V resolution 10 fA / 0.5 V
MPSMU
Triaxial cable
Sense
Force
B1500A
MPSMU
Sense
Force
Interlock cable
HPSMU
Sense
Force
HPSMU
Sense
Force
Connector plate
Fixture/Prober
DUT
Interlock
Coverage of Configuration Example
G
D
Subs
S
