Keysight B1500A Configuration and Connection Guide, Edition 6 4-23
Connection and Ordering Examples
Four terminal device
Table 4-31 Target device and application
Table 4-32 Key specification
Table 4-33 Configuration Example
Device Application Note
Memory Endurance test, Erase and V
th
test, Write
and V
th
test, Retention test, Word disturb
test
Requires 2 pulse channels
FET Charge pumping
Item Range Note
Maximum I/V range 100 mA / 100 V
Minimum I/V resolution 10 fA / 0.5 V
Model option Description Qty
B1500A Semiconductor Device Analyzer Mainframe 1
B1500A-015/030 1.5 m or 3 m length of bundled cables 1
B1500A-A04 Flash memory cell measurement basic package 1
B1500A-A5F Test fixture for packaged device measurement, adds one 16442B (Optional) 1
