Keysight E5061B - Protection Against Electrostatic Discharge (ESD)

Installation 1
Network Analyzer 21
Protection Against Electrostatic Discharge (ESD)
Set up a static-safe work-station to protect the electronic
components from the damage by the electrostatic discharge
(ESD) as shown in Figure 2.
Requirements
Back ≤ 180 mm
Sides ≤ 60mm (both right and left)
Figure 1 Ventilation space at the installation
e5061b060
50 !
DC Bias
DC Bias
1M
! /50 !
1M! +26 dBm RF
 50! +26 dBm RF
42 V DC Max CAT Ι
7 V DC Max CAT Ι
50 !
+20 dBm RF 7 V DC Max CAT Ι
±42V Peak Max Output
ELECTROSTATIC DISCHARGE
OR EXCESSIVE INPUT VOLTAGE
MAY DAMAGE CIRCUITS.
Avoid Static
OO
OO
OO
NOTE
Place the E5061B in a proper position as show in Figure 1.
