28 Network Analyzer
1 Installation
Power Supply
Before turning on the E5061B power, check the following.
Verification of the Power Supply
Confirm that the power supplied to the E5061B meets the
following requirements:
Verification and Connection of Power Cable
The three-wire power cable attached to the E5061B has one
wire serving as a ground. Using this power cable allows the
E5061B to be grounded, thereby protecting you against
electrical shock from the power outlet.
Step 1. Confirm that the power cable is not damaged.
Step 2. Use the supplied cable to connect between the
power cable receptacle (Figure 5 on page 31) on the rear panel
of the E5061B and a three-wire power outlet with the grounding
prong firmly connected in the ground slot.
Power cord list, 16000-99101 shows the power cable options.
Requirements
Voltage 90 to 132 VAC or 198 to 264 VAC
*1
* 1. Switched automatically by the E5061B in conformity to the voltage used.
Frequency 47 to 63 Hz
Maximum power
consumption
300 VA
WARNING
NEVER use a power cable showing any sign of damage. Faulty
cables can cause electrical shock.
WARNING
Use the supplied power cable with grounding wire to securely
ground the E5061B.
