22 Network Analyzer
1 Installation
Ensuring Adequate Free Space around Analyzer for Immediate
Disconnection of Power Cable in Case of Emergency
As described in “Disconnection from Supply Source" on page 31,
the power supply is disconnected by removing the power cable’s
connector plug from either the AC outlet or the E5061B unit.
When installing the E5061B, ensure that there is sufficient free
space around the unit to permit quick disconnection of the plug
(from AC outlet or E5061B unit) in case of emergency.
Figure 2 Example of the static-safe work station
