Measure S-Parameters (NA Mode) continued
The following NA Mode settings can be made before or
after calibrating without affecting measurement
accuracy.
- Press Scale/Amptd to change scale.
- Autoscale Adjusts the Y-axis to comfortably fit
the Min and Max amplitude of the active trace.
- Autoscale All Autoscales all the traces on the
screen. Useful for multi-trace configurations.
- Scale Manually enter a scale per division to view
specific areas of the trace.
- Ref Level Manually set the value of the reference
line.
- Ref Pos Manually set the position of the
reference line. Values must be between 0 (TOP
line) and 10 (BOTTOM line)
- Press Measure 1 then Format to change the
format for the measurement.
- Press BW 2 then Average then enter a value for
the number of trace sweeps to average.
- Press Marker then enter a value to move the
marker to the X-axis position of interest.
- Press Limit 8 then Edit Limits or Recall Limits to
test measurement results against limit lines.
