1-6 N67xx DUT Power Supply Installation
Connecting the Output Cables
These instructions are for a system being configured for the first time.
1 Wire the connector to the output cable.
For N6751 and N6746, the cable must be secured with a strain relief.
2 Connect the output cables from the DUT power supply to the ASRU card. Refer
to the procedure for DUT power supply model you are installing.
– Connecting Output Cables for N6751
– Connecting Output Cables for N6752
– Connecting Output Cables for N6773
– Connecting Output Cables for N6746
Figure 1-4 DUT power supplies (rear view of testhead in service position)
When adding a supply, the configuration of existing supplies
may prevent you from following all of these procedures.
Do not reconfigure existing supplies. Reconfiguring existing
supplies is likely to cause previously developed board tests to
fail.
