1-26 N67xx DUT Power Supply Installation
Programming the GPIB Address on Power Supplies
Table 1-8 shows the valid GPIB addresses for DUT power supplies. Be sure not to
duplicate a GPIB address if making changes.
Set the GPIB address from the front panel of the DUT power supply.
1 Press ADDR and enter the address.
2 Press ENTER.
Table 1-8 DUT Power Supply Addressing
Power Supply Connection GPIB Address Device File (in /dev/)
Module 0, ASRU Card channels 1-4
Module 0, ASRU Card channels 1, 2, 5, 6
22 ps0
Module 1, ASRU Card channels 1-4
Module 1, ASRU Card channels 1, 2, 5, 6
23 ps1
Module 2, ASRU Card channels 1-4
Module 2, ASRU Card channels 1, 2, 5, 6
24 ps2
Module 3, ASRU Card channels 1-4
Module 3, ASRU Card channels 1, 2, 5, 6
25 ps3
Module 0, ASRU Card channel 5 or 5-6 26 ps4
Module 0, ASRU Card channel 6 27 ps5
Module 1, ASRU Card channels 5-6 28 ps6
Module 1, ASRU Card channel 6 29 ps7
Module 2, ASRU Card channels 5-6 1 ps8
Module 2, ASRU Card channel 6 2 ps9
Module 3, ASRU Card channels 5-6 3 ps10
Module 3, ASRU Card channel 6 4 ps11
Module 0, ASRU Card channel 3 12 ps20
Module 0, ASRU Card channel 4 13 ps21
Module 1, ASRU Card channel 3 15 ps22
Module 1, ASRU Card channel 4 16 ps23
Module 2, ASRU Card channel 3 18 ps24
Module 2, ASRU Card channel 4 19 ps25
Module 3, ASRU Card channel 3 20 ps26
Module 3, ASRU Card channel 4 30 ps27
