Electronic Calibration Modules Reference Guide 1-13
General Information
Models and Options
Table 1-4 N469xD Modules
Model
Number
Connector
Type
Operating
Frequency
a
Port A and B Option
-m- and -f- -m- and -m- -f- and -f-
N4690D Type-N 50 ohm DC to 18 GHz (0DC) N4690D-M0F N4690D-M0M N4690D-F0F
300 kHz to 18 GHz (003)
N4691D 3.5 mm DC to 26.5 GHz (0DC) N4691D-M0F N4691D-M0M N4691D-F0F
300 kHz to 26.5 GHz (003)
N4692D 2.92 mm DC to 40 GHz (0DC) N4692D-M0F N4692D-M0M N4692D-F0F
10 MHz to 40 GHz (100)
N4693D 2.4 mm DC to 50 GHz (0DC) N4693D-M0F N4693D-M0M N4693D-F0F
10 MHz to 50 GHz (100)
N4694D 1.85 mm DC to 67 GHz (0DC) N4691D-M0F N4691D-M0M N4691D-F0F
10 MHz to 67 GHz (100)
N4696D 7.0 mm DC to 18 GHz (0DC) n/a n/a n/a
300 kHz to 18 GHz (003)
a. Option 0DC frequency range is DC to xx.x GHz. Option 003 frequency range is 300 kHz to xx.x GHz. Option 100 frequency range
is 10 MHz to xx.x GHz.
N469xD Other
Options
Description
A6J Adds ANSI Z540-1-1994 Calibration
1A7 Adds ISO 17025 Calibration + Uncertainties + Guardbanding
UK6 Adds commercial calibration certificate with measured data.
SPS Post Sales Support
00A Adds one -m- to -m- and one -f- to -f adapter
–– ECal ruggedized plastic storage box – Order spare storage box with foam part number 1540-2345.
