Keysight PNA-X Series User Manual

REF 2
RCVR R2 IN SOURCE OUT
PORT 2
RCVR B IN CPLR ARM
SOURCE OUTCPLR THRU
+15 dBm +30 dBm
+30 dBm +20 dBm
+15 dBm +15 dBm
REF 1
SOURCE OUT
RCVR R1 IN
PORT 1
CPLR ARM RCVR A IN
CPLR THRUSOURCE OUT
+15 dBm
+30 dBm
+30 dBm
+30 dBm
+15 dBm
+15 dBm
0.1 dB compression level:
–5 dBm typical at 26.5 GHz
PNA-X N5242A Network Analyzer
Figure 21. PNA-X N5242A network analyzer front panel connectors.
PNA N5222A Network AnalyzerPNA-L N523xA Network Analyzer
37 | Keysight | Antenna Test – Selection Guide

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
