Keysight Streamline Series Configuration Guide

15
dataTec ▪ Ferdinand-Lassalle-Str. 52 ▪ 72770 Reutlingen ▪ Tel. 07121 / 51 50 50 ▪ Fax 07121 / 51 50 10 ▪ info@datatec.de ▪ www.datatec.de
Find us at www.keysight.com Page 15
85052C precision TRL: DC to 26.5 GHz. Includes:
•
00902-60003 3.5 mm (m) fixed load
•
00902-60004 3.5 mm (f) fixed load
•
85052-60006 3.5 mm (m) short
•
85052-60007 3.5 mm (f) short
•
85052-60008 3.5 mm (m) open
•
85052-60009 3.5 mm (f) open
•
85052-60032 3.5 mm (f) to 3.5 mm (f) adapter
•
85052-60033 3.5 mm (m) to 3.5 mm (m) adapter
•
85052-60034 3.5 mm (f) to 3.5 mm (m) adapter
•
85052-60035 3.5 mm short TRL line
•
85052-60036 3.5 mm long TRL line
85052D economy: DC to 26.5 GHz. Includes:
•
00902-60003 3.5 mm (m) fixed load
•
00902-60004 3.5 mm (f) fixed load
•
85052-60006 3.5 mm (m) short
•
85052-60007 3.5 mm (f) short
•
85052-60008 3.5 mm (m) open
•
85052-60009 3.5 mm (f) open
•
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
•
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
•
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Electronic calibration (ECal) modules
85093C RF ECal: 300 kHz to 9 GHz, 2-ports. Standard module includes:
•
Option 00F: Both 3.5 mm connectors are female
•
Option 00M: Both 3.5 mm connectors are male
•
Option M0F: One female and one male connector, both 3.5 mm
•
Option 00A adds:
o
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
o
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
•
Option 150: Replaces standard storage container with a wooden box

Keysight Streamline Series Specifications

General

Brand	Keysight
Model	Streamline Series
Category	Measuring Instruments
Language	English
