Keysight Streamline Series Configuration Guide

22
dataTec ▪ Ferdinand-Lassalle-Str. 52 ▪ 72770 Reutlingen ▪ Tel. 07121 / 51 50 50 ▪ Fax 07121 / 51 50 10 ▪ info@datatec.de ▪ www.datatec.de
Find us at www.keysight.com Page 22
For devices with 7 mm connectors
Mechanical calibration kits
85050B standard: DC to 18 GHz. Includes:
•
00909-60008 7 mm coax termination
•
85050-60006 7 mm fixed broadband load
•
85050-80007 7 mm short
•
85050-80010 7 mm open
•
85050-80011 7 mm sliding load
85050C precision TRL: DC to 18 GHz. Includes:
•
00909-60008 7 mm coax termination
•
85050-60003 7 mm to 7 mm airline
•
85050-60005 7 mm to 7 mm TRL adapter
•
85050-60006 7 mm fixed broadband load
•
85050-80008 7 mm short
•
85050-80009 7 mm short with collect
•
85050-80010 7 mm open
85050D economy: DC to 18 GHz. Includes:
•
85050-60006 7 mm fixed broadband load
•
85050-80007 7 mm short
•
85050-80010 7 mm open
Electronic calibration (ECal) modules
N4696D Microwave ECal: DC or 300 kHz to 18 GHz, 2-ports, 7 mm connectors. Includes:
•
Option 0DC: DC to 18 GHz
•
Option 003: 300 kHz to 18 GHz
For devices with waveguide
Mechanical calibration kits
X-Band
X11644A standard, WR-90: 8.2 to 12.4 GHz. Includes:
•
00896-60008 X-band standard section
•
00910-60003 X-band termination
•
11644-20018 X-band short
•
11644-20021 X-band shim
•
X281C adapter (included in calibration kit): WR-90 to 7 mm
