P Band
P11644A standard, WR-62: 12.4 to 18 GHz. Includes:
•
00896-60007 P-band standard section
•
00910-60002 P-band termination
•
11644-20017 P-band short
•
11644-20020 P-band shim
•
P281C adapter (included in calibration kit): WR-62 to 7 mm
K Band
K11644A standard, WR-42: 18 to 26.5 GHz. Includes:
•
00896-60006 K-band standard section
•
00910-60001 K-band termination
•
11644-20016 K-band short
•
11644-20019 K-band shim
K281C adapter (included in calibration kit): WR-42 to 3.5 mm (f) Option 012 WR-42 to 3.5 mm (m)
R Band
R11644A standard, WR-28: 26.5 to 40 GHz. Includes:
•
00914-20028 R-band termination
•
11644-20005 R-band short
•
11644-20003 R-band shim
•
11644-60001 R-band 10 cm straight waveguide
•
11644-60016 R-band 5 cm straight waveguide
Q Band
Q11644A standard, WR-22: 33 to 50 GHz. Includes:
•
11644-60005 Q-band termination
•
11644-20004 Q-band short
•
11644-20001 Q-band shim
•
11644-60002 Q-band 10 cm straight waveguide
•
11644-60017 Q-band 5 cm straight waveguide
U Band
U11644A standard, WR-19: 40 to 60 GHz. Includes:
•
11644-60006 U-band termination
•
11644-20004 U-band short
•
11644-20002 U-band shim
•
11644-60003 U-band 10 cm straight waveguide
•
11644-60018 U-band 5 cm straight waveguide
