Measuring inductance (L)
Set up your LCR meter to measure inductance as shown in Figure 2-3.
1 Press to power on the LCR meter.
2 Press to select a suitable test frequency, and
a press to enable the auto identification function; or
b alternatively press to select inductance measurement.
Figure 2-2 Inductance measurement with Q factor
3 Insert an inductor into the component socket or connect the test clip to the
component leads as required.
4 Press to change the secondary display measurement (D, Q, or θ).
5 Read the displays.
It is recommended that you perform the Open/Short calibration (see page 62)
before testing to achieve optimum precision for all inductance, capacitance, and
resistance measurements at either the highest or lowest ranges.
